Elmo PX-30E Document camera

PRODUCT CODE #: 1375

Overview

With an unprecedented 288x zoom, the PX-30E captures in ultra-vibrant 4K resolution and records video at 30fps that can be saved via SD card, USB flash device, or the camera’s internal memory. PX-30E comes with a variety of shooting modes including 4:3 and widescreen 16:9, with a capture area of up to A4 portrait and A3 landscape. The PX-30E also features an all-new 5” High-Resolution LCD preview monitor with sleek touch-screen navigation designed for easy camera control, a zoom toggle wheel with autofocus, as well as a variety of output options (HDMI, VGA, USB, HDBaseT and TCP/IP control). The platform stage is magnetic and comes with a custom whiteboard surface that can be written on with dry erase markers to show lessons and annotate during demonstrations.

Key Features

Enhancements from the PX-30 model include a zoom dial and auto focus button on the camera head, upgraded LED light to reduce glare, HDMI cable connection locks, reduced height jog dial that bring it flush to the stage, quicker brightness control response, an operation panel lock-out feature, and a wake on LAN feature.
K-12
Higher Ed
Business & Corporate
Courtroom & Legal
Medical & Hospitals
Museums & Archives

Ultra 4K Image

The PX-30E has a specially crafted lens that captures rich Ultra 4K image and can record video in 4K at 30fps and Full HD at 60fps.

288x Zoom

With 12x optical, 12x digital zoom, and 2x sensor zoom, the PX-30E is capable of an incredible 288x zoom so you can see every vibrant detail.

Touch Navigation

The PX-30E comes with an all-new 5” High-Resolution LCD preview monitor with sleek touch-screen navigation designed for easy camera control and a zoom toggle wheel with autofocus.

Multiple Outputs

The PX-30E offers HDMI, VGA, USB and HDBaseT output options for compatibility with a wide array of products. Also comes with TCP/IP control.

Widescreen Mode

The PX-30E comes with a variety of shooting modes including 4:3, widescreen 16:9, and a capture area of up to A4 portrait and A3 landscape.

Main Camera
IMAGE PICK-UP DEVICE	12 Megapixel CMOS
EFFECTIVE PIXELS	3840 x 2160 (16:9) 8.3M 3620 x 2640 (4:3) 9.3M
RESOLUTION	1,600 TV lines (center)
ZOOM	12x Optical / 12x Digital / 2x Sensor
FOCUS MODE	Zoom sync AF / One-push AF
FOCUS RANGE	WIDE end: 5cm～∞ TELE end: 20cm～∞
SHOOTING AREA	17" x 12.6" (4:3) up to A4
ILLUMINATION	Upper light (LED)
HDMI OUTPUT	4K, 1080p, 720p
RGB OUTPUT	1080p, 720p
USB OUTPUT	4K, 1080p, 720p, QUXGA, UXGA, XGA
HDMIBASET OUTPUT	4K, 1080p, 720p
NETWORK CONTROL	TCP/IP Control
IMAGE ADJUSTMENT	Brightness, White balance, Contrast, Contour Correct, Image mask
IMAGE MODES	Normal, Emphasis, Color emphasis, Black/White, DLP Projector

General
OPERATION PANEL	Power, AF, Brightness, Freeze, Image Rotation, Capture Image, Video Record, Settings, Input Selection
LCD PANEL	HQ (800x480) 5" CApacitive-type
INPUT TERMINAL	HDMI x2, RGB Dsub15x1
EXTERNAL CONTROL	RS-232C (inc. setting menu lock), USB, Remote Control, Network Control
RECORDING/PLAYBACK	SD card, USB flash device (only photo), internal memory storage
AUDIO	INPUT: External microphone (HDMI) OUTPUT: Line out
DIMENSIONS	11.7" x 19" x 18.8" (set up) 11.7" x 19" x 3.75" (folded)
WEIGHT	9.9lbs

The ELMO PX-30E Document Camera is a cutting-edge device that revolutionizes the way you capture and present visual content. With its unprecedented 288x zoom capability, this document camera ensures that every detail is captured in ultra-vibrant 4K resolution. Whether you're presenting in an educational, business, or government setting, the PX-30E is the perfect tool to enhance your presentations and effectively convey your message.

Featuring a variety of shooting modes, including 4:3 and widescreen 16:9, the PX-30E allows you to capture content in a range of formats to suit your needs. The platform stage is magnetic and comes with a custom whiteboard surface that can be written on with dry erase markers, allowing you to annotate and highlight important information during demonstrations or lessons.

The PX-30E is equipped with an all-new 5-inch High-Resolution LCD preview monitor with sleek touch-screen navigation, making it incredibly easy to control the camera and zoom in on specific details. With the zoom toggle wheel and autofocus feature, you can effortlessly capture and focus on specific areas of interest.

This document camera offers multiple output options, including HDMI, VGA, USB, HDBaseT, and TCP/IP control, ensuring compatibility with a wide array of products and devices. Whether you're connecting to a display, projector, or computer, the PX-30E has you covered.

With its specially crafted lens, the PX-30E captures rich Ultra 4K images and can record video in Full HD at 60fps, providing you with exceptional visual quality. Furthermore, it offers a range of image adjustment options, including brightness, white balance, contrast, contour correction, and more, allowing you to fine-tune your visuals to perfection.

Compact and lightweight, the PX-30E is highly portable and can be easily set up or folded for convenient storage and transportation. It also comes with advanced features such as operation panel lock-out, wake on LAN, and HDMI cable connection locks, ensuring maximum security and ease of use.

Whether you're a teacher, presenter, or professional, the ELMO PX-30E Document Camera is a game-changer that elevates your visual presentations to new heights. Experience the power of ultra-vibrant 4K resolution and unparalleled zoom capabilities with the PX-30E.

Product Features

Ultra 4K Image

The PX-30E has a specially crafted lens that captures rich Ultra 4K image and can record video in 4K at 30fps and Full HD at 60fps.

288x Zoom

With 12x optical, 12x digital zoom, and 2x sensor zoom, the PX-30E is capable of an incredible 288x zoom so you can see every vibrant detail.

Multiple Outputs

The PX-30E offers HDMI, VGA, USB and HDBaseT output options for compatibility with a wide array of products. Also comes with TCP/IP control.

Widescreen Mode

The PX-30E comes with a variety of shooting modes including 4:3, widescreen 16:9, and a capture area of up to A4 portrait and A3 landscape.

Introducing the Elmo PX-30E Document Camera, a game-changer for visual presentations across various fields. With its remarkable 288x zoom and ultra-vibrant 4K resolution, you'll capture every detail with stunning clarity. Record videos at 30fps, saving them easily via SD card or USB flash device.

The PX-30E features:

- All-new 5” High-Resolution LCD preview monitor with touch-screen navigation
- Multiple shooting modes, including 4:3 and widescreen 16:9
- Robust output options: HDMI, VGA, USB, HDBaseT, and TCP/IP control
- A magnetic platform stage with a writable custom whiteboard surface

Enhancements from the previous model include a zoom dial, upgraded LED light, and a convenient operation panel lock-out feature. Perfect for educational institutions, corporate settings, legal environments, medical facilities, and museums, the Elmo PX-30E ensures your presentations are both engaging and professional. Elevate your visual storytelling today!
